Malibu Hydro
System Status at April 03 2026 08:50:16.
Next update in 29 minutes 22 seconds.
Web page created Oct 15, 2007
Return to main index page
HMI Screen shot - when activated, clock time is not set.
McCannel Lake Status - live data. Battery failed after ten years, will be replaced.
| Lake level |
005.0 ft |
| Weir overflow |
000.5 ft |
| Lake temperature |
039.0 C |
| Air temperature |
006.0 C |
| Battery voltage |
013.0 V |
| RTU up counter |
015.0 |
Photo by Gil Dec 24
Malibu Hydro Dam Status
When battery at 11.5 volts the RTU is programmed to shut down, it is not the sensors. Water temp sensor has failed.
| Dam water level |
058.0 cm |
| Header pipe level |
062.5 cm |
| Filter differential |
123.0 cm |
| Excess over flow |
008.0 cm |
| Dam Water temp |
087.0 C |
| Dam Air temp |
004.0 C |
| Battery voltage |
013.6 V |
| RTU up counter |
033.0 A |
580 kW Generator Status
Sensors to be installed as available.
| Bearing 1 temp |
000.0 C |
| Bearing 2 temp |
000.0 C |
| Generator air temp |
? C |
| Inside temperature |
? C |
| HPU / PLC Battery V |
000.0 V |
| Deflector position |
? % |
| SCADAC Battery V |
? V |
| Penstock pressure |
? psi |
| Up Counter |
002.0 |
